High Strength Open Die Cylinder Parts Forgings API For Metallurgy cylinder forging
| Place of Origin | China |
|---|---|
| Certification | MTC, Chemical composition, mechanical properties, UT, MT, dimension report, heat treatment record et |
| Minimum Order Quantity | 1 piece |
| Packaging Details | Fumigation-free wood package or steel package |
| Delivery Time | 40 days or as per the actual inquiry |
| Payment Terms | 30% prepayment by T/T, the balance against the receipt of the correct test certificates or as per cu |
| Supply Ability | 100 pieces per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Product Description
High Strength Open Die Cylinder Parts Forgings API For Metallurgy , Hot Die Forgings
Open die forging, Cylinder forging, cylinder part, cylinder piston, cylinder seat, cylinder component
DIN open die forging 16Mn, 20MnMoNb Alloy Steel Tube Sheet Plate, pressure vessel tube sheet, Disc Forgings, tube sheet
Quick Detail:
1. Open die forging: Cylinder forging, cylinder part, cylinder piston, cylinder seat, cylinder component
2. The material is alloy steel, carbon steel, stainless steel or other material determined by customer.
3. High strength, high temperature resistance, high corrosion resistance.
Description:
The cylinder forging, such as cylinder part, cylinder component, cylinder piston, cylinder seat or cylinder
sleeve is mainly used for pressure vessel industry
The manufacturing equipment is 30~185MN hydraulic press, the forging ratio >3, the technical condition is in
accordance with the standard of ASTM, EN, DIN, GB.
Applications:
The cylinder forging, such as cylinder part, cylinder component, cylinder piston, cylinder seat or cylinder
sleeve is mainly used for pressure vessel industry.
Specifications:
|
Description |
Cylinder forging, cylinder part, cylinder piston, cylinder seat, cylinder component |
|
material |
Carbon steel, alloy steel, stainless steel or other kind of material |
|
Material standard |
ASTM, EN or ISO etc. |
|
Dimension |
As per the customer’s requirements |
|
Weight |
Max. 50 ton |
|
Smelting Process: |
EF+LF + VD |
|
Process |
Ingot→heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough machining→UT →2nd Heat treatment →finishing machining →Inspection |
|
UT standard |
ASTM B, EN, DIN |
Competitive Advantage:
Quality control and management to the whole produce process, including ingot smelting, forging, heat
treatment, machining and strictly final inspection prior to delivery.
Excellent product quality and service, competitive price, “in-time” delivery
Why us?
1) We have an optimistic team, which will help to finish producing efficiently, so guaranteeing delivery in time.
2) We own good reputation all over the world, no matter in quality or delivery time or packaging.
3) With enough experience of forging different material, we could provide solutions.
The factory is certified by API, we have rich experience in the business of pressure vessel forgings.
