4340 EN26 Alloy Steel / Carbon Steel Forgings Custom OEM For Pressure Equipment
| Place of Origin | China |
|---|---|
| Certification | MTC, Chemical composition, mechanical properties, UT, MT, dimension report, heat treatment record et |
| Minimum Order Quantity | 1 piece |
| Packaging Details | Fumigation-free wood package or steel package |
| Delivery Time | 40 days or as per the actual inquiry |
| Payment Terms | 30% prepayment by T/T, the balance against the receipt of the correct test certificates or as per cu |
| Supply Ability | 100 pieces per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Product Description
4340 EN26 Alloy Steel / Carbon Steel Forgings Custom OEM For Pressure Equipment
Open die forgings: cylinder sleeve, barrel forging, cylinder forging
DIN open die forging 16Mn, 20MnMoNb Alloy Steel Tube Sheet Plate, pressure vessel tube sheet, Disc Forgings, tube sheet
Quick Detail:
1. Open die forging: cylinder sleeve, barrel forging, cylinder forging
1. Alloy steel, carbon steel or as per customer’s requirements
2. High strength, high temperature resistance, high corrosion resistance.
Description:
Open die forgings such as cylinder sleeve, barrel forging and cylinder forging can be made of alloy steel,
carbon steel or other kind of material as per the customer’s requirements. It conforms to the standard of ASTM, EN, DIN, GB.
The manufacturing equipment is 30~185MN hydraulic press, the forging ratio >3, the technical condition is in
accordance with the standard of ASTM, EN, DIN, GB.
Applications:
The cylinder sleeve, barrel forging, cylinder forging etc. are used for pressure vessel. The forged part can
make sure the enough hardness and properties for the heavy machinery and equipments.
Specifications:
|
Description |
Cylinder sleeve, barrel forging, cylinder forging |
|
material |
Alloy steel (4140, 4340, EN26 etc.), carbon steel, stainless steel etc. |
|
Material standard |
ASTM, ISO and EN etc. |
|
Dimension |
Max.OD:6000mm Max. Length: 5000mm |
|
Weight |
Max. 100 ton |
|
Smelting Process: |
EF+LF + VD |
|
Process |
Ingot→heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough machining→UT →2nd Heat treatment →finishing machining →Inspection |
|
UT standard |
ASTM A388 or EN10228 |
Competitive Advantage:
Quality control and management to the whole produce process, including ingot smelting, forging, heat
treatment, machining and strictly final inspection prior to delivery.
Excellent product quality and service, competitive price, “in-time” delivery
Why us?
1) We have an optimistic team, which will help to finish producing efficiently, so guaranteeing delivery in time.
2) We own good reputation all over the world, no matter in quality or delivery time or packaging.
3) With enough experience of forging different material, we could provide solutions.
Barrel type forgings can be used for many kinds of steel part, such as pipeline, cylinder etc. Customers feel
satisfied with our products and service.
