    Product Details:

    Place of Origin: China
    Certification: MTC, Chemical composition, mechanical properties, UT, MT, dimension report, heat treatment record et

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Packaging Details: Fumigation-free wood package or steel package
    Delivery Time: 60 days or as per the actual inquiry
    Payment Terms: 30% prepayment by T/T, the balance against the receipt of the correct test certificates or as per cu
    Supply Ability: 100 pieces per month
    Contact Now
    Detailed Product Description

    EF + LF + VD Ship Forged Steel Shaft ASTM EN DIN GB , Hot Roll / Cold Roll Shaft Forging



    Forged alloy steel rolls;forging white cast iron rolls, bending rollers, hot roll, cold roll, backup roll



    Quick Detail:



    1. Forged alloy steel rolls; forged steel rolls half; forging semi-high speed steel rolls; forging white cast iron

    rolls, bending rollers, hot roll, cold roll, backup roll.

    2. Common cold roll rolls of material to work there 9Cr, 9Cr2, 9Crv, 8CrMoV so cold roll requires surface

    hardening, hardness HS45 ~ 105. Hot roll commonly used materials 55Mn2, 55Cr, 60CrMnMo, 60SiMnMo etc.

    3. Mature production capacity, good quality, good service, short delivery time



    Description:



    Forged steel shaft-forged roller, rolling shaft is widely used for mining equipment or metallurgical

    equipment industry.



    It conforms to the standard of ASTM, EN, DIN, GB.



    The manufacturing equipment is 30~185MN hydraulic press, the forging ratio >3, the technical condition is in

    accordance with the standard of ASTM, EN, DIN, GB.



    The product can be provided as per your drawing or specified requirements.



    Smelting Process:EF+LF + VD



    Specifications:



    Description

    Forged alloy steel rolls; forged steel rolls half; forging semi-high speed steel rolls; forging white

    cast iron rolls, bending rollers, hot roll, cold roll, backup roll.

    material

    Common cold roll rolls of material to work there 9Cr, 9Cr2, 9Crv, 8CrMoV ;Hot roll commonly

    used materials 55Mn2, 55Cr, 60CrMnMo, 60SiMnMo etc.

    Material standard

    ASTM or GB/T3077-1999

    Dimension

    Max.OD: 2000mm

    Max. Length: 15000mm

    Weight

    Max.150 ton

    Smelting Process:

    EF+LF + VD

    Process

    Ingot→heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough

    machining→UT →2nd Heat treatment →finishing machining →Inspection

    UT standard

    ASTM A388 or EN10228





    Applications:

    Roll mill is an important part on the rolling mill, or using a pair of pressure generated when the rolling mill roll to roll steel. It is mainly exposed to static and dynamic loads during rolling, abrasion and temperature changes.



    Competitive Advantage:



    1. Good mechanical properties;

    2. High tensile strength;

    3. Well-closed formation;

    4. Comparative price;

    5. High-quality production;

    6. Customized services, manufacturing according to your specific requirements



    Why us?



    1. Short production time, “in-time” delivery;

    2. We can provide the steel forgings whatever size, material or type as per your requirements;

    3. Good quality and competitive price

    Quality control and management to the whole produce process, including ingot smelting, forging, heat treatment, machining and strictly final inspection prior to delivery.

    Excellent product quality and service, competitive price, “in-time” delivery

    Roller is a kind of normal steel forging, we have years experience for the roller shaft forging and our customers feel satisfied with our products and service.
