Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO

  • Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO
  • Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO
  • Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO
  • Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO
Place of Origin China
Brand Name XZZ
Certification N/A
Model Number N/A
Minimum Order Quantity 1 piece
Price USD100-10000 per piece
Packaging Details Plastic film wrapped first, Iron and wood pallet. All wood to fumigated in accordance with ISPM 15.
Delivery Time 20-60 working days
Supply Ability 100 pieces per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO




Open die forging, wind tower ring, wind tower flange, tower flange, wind tower forging, ring flange, steel flange

Steel forgings: wind power part forging, shaft forging, main shaft, wind shaft, wind turbine


Quick Detail:

1. wind tower ring, wind tower flange, tower flange, wind tower forging, ring flange, steel flange.

2. Alloy steel, carbon steel, stainless steel and Hastelloy or as per customer’s requirements

3. Non-standard and common or uncommon sizes diameter flange for wind power industry


Description:

Open die forging: wind tower ring, wind tower flange, tower flange, wind tower forging, ring flange,

steel flange,these forging can be made of alloy steel, carbon steel, Hastelloy or other kind of material

as per the customer’s requirements. It conforms to the standard of ASTM, EN, DIN, GB.
Open Die Rolled Ring Flange Forging Stainless Steel And Hastelloy EN10228 ISO


Specifications:

Description Open die forging: wind tower ring, wind tower flange, tower flange, wind towerforging, ring
flange, steel flange.
material Alloy steel (42CrMo4, 35CrMo, 40CrNiMo etc.), carbon steel or stainless steel
Material standard ASTM, En or ISO
Dimension Max.OD: 7000mm
Max. thickness: 1000mm
Max. height: 1500mm
Weight Max. 250 ton
Smelting Process: EF+LF + VD
Process Ingot→heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough
machining→UT →2nd Heat treatment →finishing machining →Inspection
UT standard ASTM A388 or EN10228




Applications:

The steel flange forging is used as wind tower flange, tower ring in the wind power industry.


Competitive Advantage:

Quality control and management to the whole produce process, including ingot smelting, forging, heat

treatment, machining and strictly final inspection prior to delivery.
Excellent product quality and service, competitive price, “in-time” delivery


Why us?

1. Good mechanical properties;
2. High tensile strength;
3. Well-closed formation;
4. Comparative price;
5. High-quality production;
6. Customized services, manufacturing according to your specific requirements.


Steel flanges are our main products, we have much production experience in this steel ring & flange

industry. Customers feel satisfied with our products and service.
