Custom Drive Shaft Stainless Steel Forgings For Mining Machinery , DIN GB ASTM A388g

Place of Origin China
Certification MTC, Chemical composition, mechanical properties, UT, MT, dimension report, heat treatment record et
Minimum Order Quantity 1 piece
Packaging Details Fumigation-free wood package or steel package
Delivery Time 40 days or as per the actual inquiry
Payment Terms 30% prepayment by T/T, the balance against the receipt of the correct test certificates or as per cu
Supply Ability 100 pieces per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Custom Drive Shaft Stainless Steel Forgings For Mining Machinery , DIN GB ASTM A388



Open die forging, open die forging, drive shaft, transmission shaft, steel shaft, shaft forging

Open die forging: trunnion; gudgeon; trunnion block, supporting shaft forging





Quick Detail:



1. Open die forging: drive shaft, transmission shaft, steel shaft, shaft forging

2. Alloy steel, carbon steel or as per customer’s requirements

3. Mature production capacity, good quality, good service, short delivery time





Description:



Open die forging: drive shaft, transmission shaft, steel shaft, shaft forging can be made of alloy steel, carbon steel or other kind of material as per the customer’s requirements. It conforms to the standard of ASTM, EN, DIN, GB.


The manufacturing equipment is 30~185MN hydraulic press, the forging ratio >3, the technical condition is in

accordance with the standard of ASTM, EN, DIN, GB.





Specifications:



Description

Open die forging: drive shaft, transmission shaft, steel shaft, shaft forging

material

Alloy steel (42CrMo4, 35CrMo, 40CrNiMo etc.), carbon steel etc.

Material standard

ASTM, GB/T3077-1999, En or ISO

Dimension

Max.OD: 2000mm

Max. Length: 15000mm

Weight

Max. 250 ton

Smelting Process:

EF+LF + VD

Process

Ingot→heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough

machining→UT →2nd Heat treatment →finishing machining →Inspection

UT standard

ASTM A388 or EN10228





Applications:



As the one of important part of transmission system of the machinery, the drive shaft, transmission shaft widely

used for marine &boat industry, Mining machinery industry etc.



Competitive Advantage:



1. Good mechanical properties;

2. High tensile strength;

3. Well-closed formation;

4. Comparative price;

5. High-quality production;

6. Customized services, manufacturing according to your specific requirements





Why us?



1. Short production time, “in-time” delivery;

2. We can provide the steel forgings whatever size, material or type as per your requirements;

3. Good quality and competitive price



Drive shaft, transmission shaft forging is our mature product, we have an record that the shortest production

time is 15 days for five pieces of drive shaft forgings. Customers feel satisfied with our products and service.
